(ABM-832A5) New Steel Rule Auto Bender Machine with Cut Crease Grinding included basic functions：Bending,Nicking,Perforation, Grinding, Bridge, Lipping, Mold Cut, Flat Cut. Supported steel rule thickness 0.45, 0.53, 0.71,1.05mm(1pt&1.5pt&2pt&3pt),height 8-32mm. China TP has been successful for many domestic and foreign die making&printing companies to provide advanced Auto Bender Machines, cost effective,technical support and excellent after sales service.
Picture of (ABM-832A5)New Steel Rule Auto Bender Machine with with Cut Crease Grinding for reference:
1.Multi-Nicking: 3pcs Nicking Saw Blade in one machine to meet different nicking size requirements;
It can also install grinding wheel to do grinding of cut crease, which can be remove burrs of cutting rule andmake more smoother for paper die cutting.
2.Bending and cutting in one,more safety of cutting. High efficiency of bending and cutting.
3.Multi-Punch tool:Including Lipping,Mold Cut,Bridge,Hole or Perforation, independent tool, easy to replace.
4.Smart software, easy to operate, multi language available.
|
Supported rule thickness(mm) |
0.71mm&1.05mm (2pt&3pt) |
|
Supported rule height(mm) |
23.80-32mm |
|
Front Min. bending size |
1.5MM |
|
Back Min. cutting size |
1.0MM |
|
Feeding precision |
±0.03mm |
|
Bending flatness |
±0.2mm |
|
Basic Functions |
Bending,Bridge,Lipping,Mold Cut,Flat Cut,Nicking,Perforation,Grinding |
|
Optional Functions |
Perforation/Hole/Cut Crease |
|
Optimal pattern format |
DXF,DWG |
|
Air supply |
0.4-0.8MPa |
|
Power supply |
AC220V,13.6A,50-60Hz |
|
Machine total power |
3KW |
|
Weight |
530KG |
|
Overall dimension |
2350x800x1520mm(LxWxH) |
|
H.S. Code |
8462230000 |
Our technical service is always available at sale@tempestmachinery.com
